Tubing-pressure (ambient) subsurface-controlled wireline-retrievable safety valves

Storm Choke™ H safety valves are ambient-type, wireline-retrievable valves that are normally closed and pre-charged with a set dome pressure. When the well flowing pressure drops below the predetermined dome-pressure charge, as a result of a rupture in the flowline or surface equipment, the dome pressure and valve spring are designed to close the valve, shutting in the well.

The H valve is used in wells producing large volumes of abrasive fluids. Its large bore is not restricted by a flow bean. The valve is designed to resist pressure surges. A metal-to-metal ball and seat is used as the primary closure mechanism.

The H valve is ideal for protecting wells with declining bottomhole pressure because this valve is tubing-pressure sensitive instead of velocity sensitive. To reopen, the valve pressure must be fully equalized either by applying pressure in the tubing from the surface or by running a prong to allow equalization from below. The valve will reopen when the tubing pressure acting on the internal piston area overcomes the dome charge.



Applications

  • Wells producing large volumes of abrasive fluids
  • Wells with declining bottomhole pressure » Wells with no provisions for surface-controlled valves

Features

  • Large bore not restricted by a flow bean
  • Metal-to-metal ball and seat
  • Designed to resist pressure surges

Benefits

  • Closes as flowing conditions change
  • Ball closure cleans itself of debris
  • Can be used in severe environment wells
  • Installed and retrieved under pressure using wireline methods
  • Adaptable to any Halliburton lock mandrel
  • Designed to locate in any Halliburton landing nipple
  • Straight-through flow path
  • Can be located on large bore intervention packers
