BaraTrap high-pressure debris unit is designed to maintain flow integrity and reduce downtime during drilling and completion operations
Talk to an expertSolids and debris in drilling and completion fluids can affect well integrity and cause operational delays. These issues often lead to troubleshooting and additional trips. Conventional traps may lack the capacity and adaptability needed for complex well designs. BaraTrap high-pressure debris unit addresses these challenges with advanced filtration technology to keep operations moving efficiently.
Dual-loop architecture and modulating bypass technology allow circulation to continue even under heavy debris loads. Independent loops with bypass capability maintain flow, while emergency bypass activates at controlled pressure thresholds. Operators can access filters from ID to OD, simplifying maintenance and reducing time on deck.
BaraTrap high-pressure debris unit is engineered for high-pressure performance up to 15,000 psi. It supports continuous circulation during critical phases such as displacement and packer setting. Its large debris capacity manages solids and swarf without back flushing, while the modular design simplifies maintenance.
Standard 1502 hammer union connections enable quick integration. Optional inserts, including stainless steel and micron-rated screens, provide tailored filtration for diverse well conditions. These features work together to improve operational efficiency and minimize disruptions.
This solution is suited for mud conditioning, riser drilling, window milling, and sidetracking during drilling. For completions, it supports mud-to-brine displacement, TCP runs, and barrier packer operations. These capabilities help reduce solids-related disruptions and improve operational efficiency.
| Specification | Value |
|---|---|
| Max working pressure | 15,000 psi |
| Safe operating rate | 30 BPM |
| Loops and chambers | 2 loops, 12 chambers |
Filter serviceability |
ID to OD |
Connections |
1502 hammer union |
Skid options |
XL: 8.6 ft W x 16 ft L x 7 ft H; M: 8.6 ft W x 8.6 ft L x 7 ft H |
